STDJ-3A Digital Multifunction Electric Portable Compactor STDJ-3A manufacturer from China Hangzhou Yueke Instrument Co.,Ltd

STDJ-3A Digital Multifunction Electric Portable Compactor

Payment Terms:	T/T,L/C;negotiable
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: STDJ-3A

Production Capacity: 15 Set/Sets / Week

Delivery Date: within 15 days after upon r...

Power: Others

key words: testing machine

Means of Transport: by sea by air

Packing: standard export woden case

Usage: Others

Brand Name: yueke

certificate: CE

1.Automatically compact specimens
2.Height are adjustable
3.ABS plastic vertical control cabinet
Electric Portable Compactor

STDJ-3A Digital Multifunction Electric Portable Compactor (Middle one blow)

Description: This machine automatically compact specimens, eliminating the laborious hand compaction method. The height and weight of the rammer The height and weight of the rammer are adjustable to suit test requirements. The rammer travels across the mould and the table rotates the mould in equal steps on a base that is extremely stable, the table also pushes forward and pulls back the mould. Compaction cycle: the mould is pushed forward and rotated, getting six blows at the side in different directions; then pulled back and got one blow in the middle. The number of blows per layer can be set at the beginning of the test.
Specification
1. Rammer: Circular faced, 50 mm dia, adjustable to 2.5 kg and 4.5 kg weight.
2. Drop: Adjustable to 300 mm and 450 mm
3. Motor:370W, 1400rotate/min.
4. Dimensions 380×640×1350 mm
5. Package weight: 260 kg
Features:1.ABS plastic vertical control cabinet.

2.Pre-set blow pattern ensures even compaction,base plate can automatically pull and push,
3. one blow in the center

Electric Portable Compactor
